Planet 8-Port Gigabit 60W Ultra PoE Managed Injector Hub
Planet
DS1_UPOE-800G
Immediatamente Disponibile
746,02 €
Tasse incluse
- Data di consegna prevista:
-
UPS EXPRESS - Acquista entro e ricevilo Martedì 13 Maggio, 2025 -
Corriere Standard - Acquista entro e ricevilo Lunedì 19 Maggio, 2025
- Interface
- 16-port RJ45
- 8-port 10/100/1000Mbps ?Data input?
- 8-port 10/100/1000Mbps ?Data + Power output?
- One 10/100/1000BASE-T management port
- 802.3bt Power over Ethernet
- Complies with IEEE 802.3bt Power over Ethernet Plus Plus
- Backward compatible with IEEE 802.3at Power over Ethernet Plus
- Up to 8 ports of IEEE 802.3at/IEEE 802.3bt PoE devices powered
- 8 PoE ports with built-in 802.3bt type-4 PoE 90W or Ultra PoE 95-watt injector function
Specifiche del prodotto
| Design | |
| Certification | FCC Part 15 Class A, CE |
| LED indicators | Yes |
| Product colour | Blue |
| Rack mounting | Yes |
| Reset button | Yes |
| Features | |
| Certification | FCC Part 15 Class A, CE |
| LED indicators | Yes |
| Maximum operating distance | 100 m |
| Product colour | Black |
| Rack mounting | Yes |
| Legal Information | |
| UNSPSC Code | 43222612 |
| Management features | |
| Switch type | Managed |
| Web-based management | Yes |
| Network | |
| 10G support | No |
| Auto MDI/MDI-X | Yes |
| Cable standard | Cat 3/4/5/5e/6 |
| Cable types supported | Cat3, Cat4, Cat5, Cat5e, Cat6 |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10, 1000 |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 90 % |
| Operating temperature (T-T) | -10 - 70 °F |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -10 - 70 °C |
| Other features | |
| Dimensions (WxDxH) | 440 x 300 x 44.5 mm |
| Ethernet interface type | Gigabit Ethernet |
| Package dimensions (verified) | |
| Depth Verified | 56,5 cm |
| Gross Weight Verified | 5,74 kg |
| Height Verified | 10 cm |
| Width Verified | 39,5 cm |
| Performance | |
| Harmonized System (HS) code | 85176990 |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 17 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Ethernet LAN (RJ-45) ports | 16 |
| Power | |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| Power consumption (max) | 520 Watt |
| Power over Ethernet (PoE) voltage | 54 V |
| Total Power over Ethernet (PoE) budget | 400 Watt |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) voltage | 54 V |
| Total Power over Ethernet (PoE) budget | 400 Watt |
| Product dimensions | |
| Net Weight (Product, kg) | 4,28 kg |
| Vendor information | |
| Brand Name | Planet |
| Warranty | 3 Anno(i) |
| Weight & dimensions | |
| Dimensions (WxDxH) | 440 x 300 x 44.5 mm |
